 RIA-90-32
Hollow Shaft Encoder
-
High Frequency Response
-
High Resolution
-
High Reliability
|
|
Electrical Specifications
|
Resolution
|
1024, 4096
|
Supply
Voltage
|
DC + 5V ±5%
|
Current
Consumption
|
140 mA
Max.
|
Frequency Response
|
204 kHz
Max.
|
Rise and
Falling Time
|
0.3 µs
|
|
Mechanical
Specifications
|
Maximum
Rotational Speed
|
3000 RPM
|
Starting
Torque
|
500gf. cm
Max. at 25°C
|
Maximum
Shaft Load
|
Radial
|
20 kg Max.
|
Axial
|
10 kg Max.
|
Vibration
Resistance
|
10 ~ 55Hz /
1.5mm
|
Shock
Resistance
|
100G / 11msec
|
Operating
Temperature Range
|
0°C ~
+70°C
|
Storage
Temperature Range
|
-20°C ~
+80°C
|
Protection
|
IP50
|
|
|
