 RIB-50-14
Solid Shaft Encoder
-
Small Compact Size
-
Wide Ranging Applications
-
High resolution
-
Measuring Instruments
-
Low Cost
|
|
Electrical Specifications
|
Resolution
|
30, 60, 100, 200,
360, 400, 500, 512, 600, 1000, 1024
|
Supply
Voltage
|
DC +
4.75 ~
28V
|
Current
Consumption
|
60 mA
Max.
|
Frequency Response
|
85 kHz
Max.
|
Rise and
Falling Time
|
3 µs
|
|
Mechanical
Specifications
|
Maximum
Rotational Speed
|
5000 RPM
|
Starting
Torque
|
30gf. cm
Max. at 25°C
|
Moment of
Inertia
|
20gf.cm²
Max.
|
Maximum
Shaft Load
|
Radial
|
5 kg Max.
|
Axial
|
3 kg Max.
|
Vibration
Resistance
|
10 ~ 55Hz /
1.5mm
|
Shock
Resistance
|
50G / 11msec
|
Operating
Temperature Range
|
-10°C ~
+50°C
|
Storage
Temperature Range
|
-25°C ~
+85°C
|
Protection
|
IP54 / IP66
|
|
|
